DESS premilled abutment holder - 3mm shaft

Holder with with 6 preface abutments
Suitable for: one +150i, 250i, 250i Loader PRO.

Highlights:

• short production times
• production of abutments in very simple processes
• high accuracy of fit due to prefabricated implant interface

Parts included to the starter kit:

1 x abutment holder with all necessary screws
6 x Prefab abutments
1 x test piece for holder calibration
1 x T3/T8/T16 - 1,5 | 3,0mm radius milling tool (l=12mm) universal
1 x T1/T6 - 3,0 | 3,0mm radius milling tool (l=15mm) Ti/CoCr
1 x T2/T7 - 2,0 | 3,0mm radius milling tool (l=12mm) Ti/CoCr
1 x T4/T9 - 1,0 | 3,0mm radius milling tool (l=9mm) Ti/CoCr
1 x optical and technical implementation of the holder into iCAM V4.7 or iCAM V5
1 x strategies for iCAM V4.7 or iCAM V5

IMPORTANT NOTE: The latest version of the CAM software is necessary to use the holder and its functions -

By default the following prefab abutments are included in the starter kit:

1x Straumann Bone Level NC (titanium)
1x Straumann Bone Level RC (titanium)
1x CAMLOG D 3,8 (titanium)
1x CAMLOG D 4,3 (titanium)
1x Nobel Biocare Replace NP 3,5 (titanium)
1x Nobel Biocare Replace RP 4,3 (titanium)

On demand you have the opportunity to include other abutments. Please notify us about the accordant modification when placing the order.
